This device is suitable in hospitals and clinics for diagnosing abdomen, urology, Cardiology, OB/GYN, small parts examination and orthopedics. Veterinary applications also available.

Full digital beamforming technology
Probe automatic identification
8-segment TGC adjustment
Digital encoder knobs
Gama correction, histogram
Automatic report generation (normal/OB)
Scanning angle adjustment
16 level scanning depth adjustment
USB 2.0 for real-time picture uploading to PC
Biobsy guide available
Back-lit keyboard

Scanning mode : Convex/Linear/Micro-convex
Display modes: B,B + B,B + M, 4B
Scanning Depth: 240mm
Gray scales: 256
Cine-loop: 819 frames (Max)
Image permanent storage: 32 frames
Image conversion: up/down, left/right, black/white
Local zoom: 2 times both in real-time and frozen
Measurement: distance, circumference, area, volume, EF rate, heart rate
OB measurements: BPD, GS, CRL, FL, AD, HC, AC, EDD, GA, FW
Probe connector: 2
Probes selectable: convex, linear, micro-convex, transvaginal and endorectal
Port: PAL-D video out, USB 2.0
Monitor: 10 inch SVGA
Body marks: 40
Comment: date & time, name, sex, age, doctor, hospital, annotation (whole screen comment input)

Standard configuration:         3.5 MHz Convex probe
Optional configuration:         7.5 MHz Linear
                                                5.0 MHz Micro-Convex
                                                            6.5 MHz Transvaginal Convex
                                                            7.5 MHZ Endorectal Linear
                                                            Video Printer
                                                            Biopsy bracket
